150kW Generator set for Man and Supply winder, Mount Isa Mines

DESCRIPTION

Description150kW generator set for the main winder motor on the Man and Suply winder. This winder used DC motor that was capable of variable speed. This was achieved by a small change in the output of the "exciter". the small generator on the right. The output from the exciter was fed into the main generator. This varied the output of the large generator which then fed into the motor. This variation changed the speed of the winder. This system was known as "Ward Leonard Contro".RightsPublic DomainCollectionReginald O'BrienSubjectMining EquipmentMiningMining Buildings

LOCATION

PlaceMount Isa MinesGeolocation^[1]

IDENTIFIERS

KeywordGeneratorWard LeonardMotor GeneratorWinderMan and SupplyTaxonomyLocation | Mount Isa MinesTopics | Mining

CONNECTIONS

OrganisationMount Isa Mines

ADMIN

Trove TypeStill Image
